Model
39x39 Kare 6 Ayak 6x6x7 Podyum
39x39 square truss · 6 legs · 6×6×7 m rig with podium
DIM6×6×7 m
Catalogue
Roof Systems
Pitched and space-frame roof systems plus podium and chain-hoist rig structures built with the square and folding triangular truss series. Configurations with different leg counts and spans provide solutions for concert, festival and event stages.
Illustrative 3D model — proportions are not to scale.
Models
Model
39x39 Katlanır 4 Ayak 8x5x7 Caraskal
39x39 folding truss · 4 legs · 8×5×7 m chain-hoist rig
DIM8×5×7 m
Model
40x52 Kare 4 Ayak 14x12x7
40x52 square truss · 4 legs · 14×12×7 m flat rig
DIM14×12×7 m
Model
40x52 Kare 8 Ayak 16x25x6 Üçgen Çatı
40x52 square truss · 8 legs · 16×25×6 m pitched roof
DIM16×25×6 m
Model
52x52 Kare 18x22x7 Üçgen Çatı
52x52 square truss · 18×22×7 m pitched roof
DIM18×22×7 m
Model
52x52 Katlanır Uzay Çatı
Space-frame roof system with 52x52 folding truss
Model
62x62 Kare 14x12+4x9 Üçgen
62x62 square truss · 14×12+4×9 m pitched roof
DIM14×12+4×9 m
Model
62x62 Üçgen 14x12+4x9 Üçgen Çatı
62x62 triangular truss · 14×12+4×9 m pitched roof
DIM14×12+4×9 m
Model
52x76 Kare 15x18+6x11 Üçgen Çatı
52x76 square truss · 15×18+6×11 m pitched roof
DIM15×18+6×11 m
Model
52x76 Kare 15x18+6x11
52x76 square truss · 15×18+6×11 m flat rig
DIM15×18+6×11 m
